Air fryer production line

Detail

Air fryer stretching and stamping production line process and introduction

1: Suitable products for the production line: This fully automatic production line is suitable for automatic stretching and stamping of various types of air fryers, soup pots, milk pots, etc.
2: Trial material: stainless steel or aluminum alloy
3: Working cycle: 8 hours or 12 hours of continuous production recommended
4: Production accounting table:

Product diameter	Product height	Pot output		Pot lid output in 8 hours
100-200mm	50-100mm	10-8 pieces/min	>2000pcs/8 hours	>3800pcs/8 hours
200-300mm	100-150mm	8-6 pieces/min	>3800pcs/8 hours	>3800pcs/8 hours
300-400mm	150-200mm	6-5 pieces/min	>2000pcs/8 hours	>3800pcs/8 hours
400-500mm	200-300mm	5-4 pieces/min	>1500pcs/8 hours	>3800pcs/8 hours

5: Production process:
Round material feeding-stretch forming-bottom forming-trimming-edging-punching-completed
6: Equipment combination and budget:
Automatic feeding machine + automatic stretching machine + forming hydraulic press + trimming punch + flanging hydraulic press + edge pressing press + punching machine + 7 robots = $200,000

Air fryer steaming plate stamping production line process and introduction

1: Suitable products for the production line: This fully automatic production line is suitable for the automated production of various types of steaming trays, shells, lids, etc.
2: Trial material: stainless steel or aluminum alloy
3: Working cycle: 8 hours or 12 hours of continuous production recommended
4: Production accounting table:

Product diameter	Product height	Pot output		Pot lid output in 8 hours
100-200mm	50-100mm	10-8 pieces/min	>2000pcs/8 hours	>3800pcs/8 hours
200-300mm	100-150mm	8-6 pieces/min	>3800pcs/8 hours	>3800pcs/8 hours
300-400mm	150-200mm	6-5 pieces/min	>2000pcs/8 hours	>3800pcs/8 hours
400-500mm	200-300mm	5-4 pieces/min	>1500pcs/8 hours	>3800pcs/8 hours

5: Production process:
Cutting - Stretching - Punching - Trimming - Shaping - Flanging - Straight edge - Complete
6: Equipment combination and budget:
Automatic wafer feeder + 6 pneumatic punches + 7 robots = $190,000

Continuous stretching of the inner pot of the electric pressure cooker, stamping production line process and introduction

1: Suitable products for the production line: This fully automatic production line is suitable for automatic stretching, trimming, punching, watermarking and thread tapping of various types of electric pressure cookers and other pot bodies.
2: Trial material: stainless steel or aluminum alloy
3: Working cycle: 8 hours or 12 hours of continuous production recommended
4: Production accounting table:

Product diameter	Product height	Pot output		Pot lid output in 8 hours
100-200mm	50-100mm	10-8 pieces/min	>2000 pcs/8 hours	>3800 pieces/8 hours
200-300mm	100-150mm	8-6 pieces/min	>3800 pcs/8 hours	>3800 pieces/8 hours
300-400mm	150-200mm	6-5 pieces/min	>2000 pcs/8 hours	>3800 pieces/8 hours
400-500mm	200-300mm	5-4 pieces/min	>1500 pcs/8 hours	>3800 pieces/8 hours

5: Production process:
Wafer feeding--stretch forming--trimming--flaring-bottom punching--bottom forming--watermark--tapping--complete
6: Equipment combination and budget:
2 automatic wafer feeders + 2 automatic stretching machines + punch trimming + hydraulic press flanging + punch punching + punch forming + watermarking machine + automatic threading machine + 5 translation manipulators = $150,000
